1.2G GSM networks
2.Waterproof IP67
3.LED rolling lights based on light sensor automatically
4.GPS positioning, with accuracy of 5m outdoor
5.Web platform/ Phone App/ SMS for positions check
6.Historical route
7.SOS button for help
8.Geofence: GPS fence
9.Step counting
10.Voice monitor
11.Low battery alarm
12.Ringtone to find your pet
13.2-way voice communication
"GSM frequency band: 850/900/1800/1900MHz
GPS positioning time:
Cold start 60sec (outdoor open sky)
Warm start 29sec (outdoor open sky)
Hot start 5sec (outdoor open sky)
GPS positioning accuracy: 5-15 meters (outdoor open sky)
Base station positioning accuracy: 100-1000 meters
Working temperature: -20℃ ~ +70℃
Working humidity: 5% ~ 95% RH
Product size: 50 (length) * 40 (width) * 15 (height) mm
Product net weight: 30 grams
Battery capacity: 600mA"
Operation system MTK
Chip platform MTK 2503
Main frequency 260MHz
Support network frequency GSM 6625S
Bands combination 850/900/1800/1900MHz
Receive diversity Supports
Data rate 2G Data: EDGE
GPS Supports
Chip module: Main chip internal integrated
GPS signal: BD2,1561,098MHz / L1,1575.42MHz C/A code
GPS channel number: 22 channels
GPS chip scale receiving sensitivity Trace:-165dBm, Capture:-148dBm
GPS accuracy 5-15m
GPS Antenna LDS/ceramic
AGPS Supports
AGPS fast position time: Cold boot within 26 sec to locate
LBS Sim base tracking Supports
LBS accuracy 100-1000M
